| Product size | 26m*5m*3m(for reference only) |
| Product structure | Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet, discarding sticker. |
| Control system | PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor |
| Drive system | Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings. |
| Tension system | Top tissue paper,bottom tissue paper,top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B shaft active unwinding by inverter motor. |
| Safety system | It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer. |
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
| Materials corrective system | Materials corrective system: Adopt international famous brand deviation correction system |
| Power | 240V, 50HZ three phase five wire |
| Machine Capacity | 400KW (Excluding glue machine and air compressor) |
| Bleed pressure | 0.6-0.8Mpa (Air compressor needs to be prepared by customers) |
| Machine weight | 70 Tons approximately |
Whatsapp: +008615805080212
Email:jessie@wm-machinery.com
https://www.diapersmachines.com
Strengthen production stability and reduce operational risks
The full servo system ensures production consistency:
Relying on the precise control of full servo drive, the parameter errors of each process on the production line (fabric conveying, core laying, cutting and pressing) can be controlled within ±0.5mm, ensuring that the size, thickness and absorption performance of each nursing pad are highly consistent, avoiding quality fluctuations caused by differences in manual operation. It is especially suitable for medical procurement orders with high requirements for product standardization, helping buyers stably obtain long-term cooperation opportunities.
Strong ability to handle unexpected situations:
Equipped with a power-off memory function, it can automatically restore previous production parameters after a brief power outage and restart, avoiding batch scrapping caused by power fluctuations. The key parts of the production line are equipped with fault early warning devices. When problems such as fabric deviation and core material shortage occur, they will promptly issue an alarm and suspend production to reduce waste generation. In response to the issue of unstable raw material batches in some areas, the servo system can fine-tune the conveying speed and pressure to accommodate minor quality differences of raw materials and ensure production continuity.
